Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication

Supply Ability : 500 units/month

Surface Treatment : Full Deep Nitrided Finish

Model Number : D28

Supporting Accessories : Complete D28 Fixture Kit Included

Payment Terms : D/A,L/C,D/P,T/T

Hole System : D28 Standard Grid System

Price : 500USD-1000USD

Available Sizes : Multiple Standard Stock Dimensions

Certification : CE

Tabletop Material : Q355 Carbon Steel

MOQ : 1

Delivery Time : 10-20 work days

Flatness Feature : High Precision CNC Milled Flatness

Max Static Load : 12 Tons Heavy Load Bearing

Brand Name : WUXI LEMAR

Application Range : Multi-industry Welding & Assembly

Place of Origin : WUXI,CHINA

Structure Design : Spliceable Combined Structure

Packaging Details : 4000mm*2000mm*200mm

Contact Now

Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication
Product Overview
Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication

The Stable Heavy D28 Positioning Welding Table is a precision work platform engineered for metal workshops where stability and accurate fabrication are top priorities. Built with a heavy, vibration-dampening structure and a precision-machined D28 positioning grid, this table provides a rock-solid foundation for high-quality welding and assembly work.

Ideal for precision metal workshops producing everything from custom machinery to high-tolerance components, this table combines heavy construction with accurate positioning capability. The solid steel top and reinforced frame absorb vibration from welding, grinding, and hammering, while the D28 hole system delivers repeatable locating accuracy for every setup.

Product Parameters
Item Parameters
Base Material Q355 low-alloy high-strength steel
Surface Treatment Five-sided full-depth integral nitriding
Surface Hardness HV 550-650
Hole Specification D28 (28mm diameter), grid spacing 100±0.05mm
Flatness Accuracy ≤0.1mm / 1000mm
Hole Center Tolerance ±0.03mm
Tabletop Thickness 25mm
Max Static Load 12 tons
Working Surfaces Five-sided operation (top plus four vertical sides)
Custom Service Multiple standard sizes
Product Advantages
Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication
1. Exceptional Stability for Precision Work

The heavy solid steel top combined with a reinforced box-section frame creates a massively stable work platform. This high-mass construction absorbs vibration from welding, grinding, and workpiece handling, ensuring that delicate setups and precision alignments are not disturbed during fabrication.

2. High-Accuracy D28 Positioning System

The precision-bored D28 holes achieve position accuracy within ±0.04 mm, thanks to state-of-the-art CNC machining and strict quality control. This level of positioning accuracy ensures consistent, repeatable fixture setups that produce dimensionally accurate parts batch after batch.

3. Precision-Ground Flat Surface

The table top undergoes precision grinding after stress relief treatment, achieving a flatness tolerance of ±0.06 mm per meter. This flat reference surface ensures that workpieces sit true and square, providing a reliable base for both welding and dimensional inspection.

4. Heavy Box-Section Frame with Cross Bracing

Beneath the table top, a robust box-section frame with full cross bracing distributes weight evenly and prevents torsional flexing. This rigid understructure maintains table flatness and alignment even when heavy workpieces are placed off-center, contributing to consistent fabrication quality.

5. Nitrided Surface for Durability and Cleanliness

The working surface receives a professional nitriding treatment that creates a hard, wear-resistant layer with HV 550 to 650 hardness. This treatment protects against welding spatter, abrasion, and surface damage, preserving the table precision and making daily cleanup fast and easy.

6. Precision Leveling Feet for Perfect Setup

Each support leg is fitted with a heavy-duty precision leveling foot that allows fine adjustment of table height and flatness. This ensures you can set up the table perfectly level on any workshop floor, providing a stable, accurate foundation for all your precision metal fabrication work.

Application Scenarios
Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication
  • Job Shops and Custom Fabrication – Fast changeover between diverse customer projects
  • Prototype development and research and development – Quick iteration and testing of new designs
  • Mixed Production Lines – Handle multiple product types on one platform
  • Heavy Equipment Manufacturing – Large, complex assemblies with frequent reconfiguration
  • Automotive and Custom Builds – One-off and small-batch custom fabrication
  • Training and Education Centers – Versatile platform for teaching welding and fixturing
Export Packaging
Stable Heavy D28 Positioning Welding Table For Metal Workshop Fabrication
  • Tabletop: The main welding table body is packed in a heavy-duty, fumigation-free solid wood plywood crate, featuring internal foam protection and reinforced corner bracing to prevent damage during ocean transit.
  • Fixture Kit: Components are individually wrapped in anti-rust paper and organized within a metal tool case.
  • Legs and Accessories: Packed in separate boxes to prevent scratching the nitrided tabletop surface during transport.
Frequently Asked Questions
Q1: How does this table achieve better stability than standard welding tables?

A: The stability comes from three key design features: a thick solid steel top plate that provides high mass, a heavy box-section frame with full cross bracing that resists flexing, and multiple support legs with precision leveling feet. This combination creates a rigid, vibration-absorbing platform that stays steady during all fabrication operations.

Q2: What is the positioning accuracy of the D28 holes?

A: The D28 holes are precision-machined with a position accuracy of ±0.04 mm. This is achieved through high-precision CNC machining and verified with coordinate measuring equipment during quality inspection. The consistent grid spacing ensures your fixtures locate exactly where expected, every time.

Q3: Can this table be used for both welding and inspection work?

A: Yes, the precision-ground flat surface and accurate hole grid make the table suitable for both welding and dimensional inspection. Many workshops use it as a dual-purpose station, welding components and then checking dimensions on the same surface to eliminate transfer errors between operations.

Q4: How does the nitrided surface compare to other surface treatments?

A: Nitriding creates a hard, wear-resistant surface layer that penetrates into the steel, rather than just sitting on top like a coating. This means the protection is durable and will not chip or peel off. The nitrided surface also naturally resists welding spatter adhesion, making cleanup much faster compared to untreated or painted surfaces.

Q5: What size table should I choose for my workshop?

A: The right size depends on your typical workpiece dimensions and available floor space. We recommend selecting a table that provides at least 200 to 300 mm of extra space around your largest workpiece to allow room for clamps and fixtures. Our technical team can help you evaluate your needs and recommend the optimal size and configuration.

Q6: How is the table leveled, and how often should I check it?

A: The table is leveled using the precision adjustment feet on each support leg. A precision level or straight edge is used to verify flatness across the table surface. For initial setup, we recommend careful leveling before first use. After that, check leveling every 3 to 6 months, or any time the table is moved or experiences a heavy impact.

Contact Us

If you run a precision metal workshop and need a welding table that combines rock-solid stability with accurate positioning, our Stable Heavy D28 Positioning Welding Table is designed to meet your standards. Our technical team can help you select the right size, evaluate your precision requirements, and recommend accessories that match your specific fabrication applications.

We offer detailed technical specifications, factory inspection reports, and optional third-party calibration certificates for customers with strict quality requirements. Whether you need a single table for your workshop or multiple units for a production facility, we provide professional guidance from selection through installation and after-sales support.

Send us your workpiece dimensions, tolerance requirements, and workshop layout information, and we will respond within 24 hours with a comprehensive quotation and technical recommendations. We also welcome custom size requests and special configuration inquiries to match your unique precision fabrication needs.
