D16 Welding Workbench with 50mm Grid Lines and Precise Laser Cut Hole Positioning

This D16 Welding Workbench with 50mm Grid Lines and Precise Laser Cut Hole Positioning is a high-precision 3D flexible modular welding platform developed for precision sheet metal, small component processing and automated robotic welding production lines.

Equipped with industry-standard Φ16 hole system and 50×50mm uniform grid layout, the tabletop adopts integrated laser cutting forming technology for all positioning holes and coordinate scales, delivering ultra-high hole position accuracy and long-lasting dimensional stability.

Different from ordinary drilling welding tables on the market, its overall nitrided steel structure brings outstanding wear, spatter and corrosion resistance, supporting multi-angle three-dimensional clamping through five-sided full hole layout. It can replace dozens of custom single-use fixtures, greatly shortening workpiece positioning time, reducing production scrap rate and creating reliable benchmark tooling for small-batch, multi-variety precision welding manufacturing.

• Zero coordinate offset: The CNC program outputs uniformly, ensuring an error of ≤±0.03mm for all holes across the entire worktable, resulting in completely uniform dimensions for batch production.
• No burrs or deformation on hole walls: The laser heat-affected zone is extremely small, preventing tensile deformation during drilling and eliminating the need for secondary polishing.
• Uniform and stable hole diameter: Thousands of holes on the entire board exhibit high dimensional consistency, ensuring smooth and unobstructed clamping.
• Coaxial alignment of grid lines and hole positions: Laser synchronous etching of the grid scale ensures precise alignment of the marking center with the center of each row of holes, resulting in zero visual positioning deviation.

• High-density hole spacing, extremely flexible: The 50mm hole spacing doubles the number of holes compared to D28 (100mm hole spacing), allowing for clamping of small parts, thin plates, and irregularly shaped components at any angle without dead angles; suitable for multi-variety, small-batch processing, one platform replaces dozens of dedicated tooling sets.
• Full 3D 5-sided positioning: D16 holes are arranged on the top surface and four sides, enabling horizontal, vertical, and oblique multi-angle clamping, allowing for one-time clamping and forming of pipes, boxes, and sheet metal frames.
• Durable and resistant to weld damage: Nitrided hardened surface, easy to clean spatter, less prone to dents and scratches, and minimal flatness degradation over long-term use.
• Universal standardized accessories: Globally universal D16 tooling system: locking pins, support blocks, angle gauges, quick clamps, U-shaped square boxes, etc., are all interchangeable, resulting in low procurement and replacement costs.
• Multi-scenario reusability: Not just a welding table, it can be used for parts assembly, dimensional inspection, grinding, and as a robot tooling reference platform.

• The entire welding table is guaranteed for 12 months; the nitriding layer of the table surface and the precision of the laser holes are guaranteed for 1 year (excluding damage from human impact or overload).
• Free replacement of parts for manufacturing defects during the warranty period; remote guidance for calibration.
• Technical support: 2-hour online response; 24-hour tooling matching solutions and drawing technical support.
• Long-term spare parts supply: D16 complete set of fixtures and locking pins are always in stock; individual purchases are possible. On-site calibration and equipment operation training services are available for large customers.
